RTV Coated Glass Insulator

Availability:

Quantity:



Inquire Add to Basket

Brand:
NJREC

Anti Fog Type Glass Insulator

Product Parameters

Type	Spacing(mm)	Diameter (mm)	Creepage Distance(mm)	Coupling	Mechanical Faiing Load(kN)
U40B	110	175	190	11	40
U70BS	127	255	320	16	70
U70BL	146	255	320	16	70
U100BS	127	255	320	16	100
U100BL	146	255	320	16	100
U120B	146	255	320	16	120
U120BS	127	255	320	16	120
U160BL	170	280	400	20	160
U160BS	146	280	400	20	160
U210B	170	280	400	20	210
U240B	170	280	400	24	240
U300B	195	330	490	24	300
U400B	205	360	550	28	420
U550B	240	380	620	32	550
U70BLP	146	280	450	16	70
U100BLP	146	280	450	16	100
U120BP	146	280	450	16	120
U160BLP	170	320	550	20	160
U160BMP	155	320	550	20	160
U160BSP	146	320	550	20	160
U210BP	170	320	550	20	210
U240BP	170	320	550	24	240
U300BP	195	380	690	24	300
U420BP	205	380	620	28	420
U550BP	240	390	710	32	550

Certificate

NJREC has built a good reputation for high quality products, timely delivery and responsive customer service. And has kept its development process, considering his responsibilities and missions about being one of the esteemed and respectful companies in the transformer bushing, transmission line and substation industry.

FAQ

Q1. What's the payment term ?

A. T/T and L/C is acceptable and TT will be more appreciated. 30% deposit, 70% balance against B/L copy.Or 100% irrevocable LC at sight.

Q2. How to buy your ideal products?

A. You can provide us with your drawings with specifications, we will produce as per your drawing.Or we can design as your requirements if you do not have a clear plan.

Q3. What is your Packing/Package ?

A. Standard export packing or Customized packing as your request.

Q4. Would you accept to use our logo ?

A. OEM/ODM can be acceptable.

Q5. What kind of certificate you have ?

A. Our company already achieve ISO9001 certificates and we have test reports.

Q6. What else can I do for you?

A. Our salesmen will reply your inquiry within 24 hours. We can give you any support on the technique & other aspects.
